Custom Membrane Keypad
OEM Service FPC Membrane Switch Keypad
Home /Products /

Membrane Switches

/

FPC Membrane Switches

/

OEM Service FPC Membrane Switch Keypad

OEM Service FPC Membrane Switch Keypad

1. OEM Tactile & Non-Tactile

2. Flexible Printed Circuit

3. Embedded LED’s, Resistors & sensors

4. Able to make to customer’s waterproof requirement & UV protection design

5. Fiber Optic & Electroluminescent Backlighting,EL  back light,  LED back light effect,  Light Guild Film (LGF or LGP)  back light, Fiber Optic Back light.

6. ESD Anti-Static Design: using Aluminum Foil, Printing AG or C plasma , ITO Film anti-static

1. OEM Tactile & Non-Tactile

2. Flexible Printed Circuit

3. Embedded LED’s, Resistors & sensors

4. Able to make to customer’s waterproof requirement & UV protection design

5. Fiber Optic & Electroluminescent Backlighting,EL  back light,  LED back light effect,  Light Guild Film (LGF or LGP)  back light, Fiber Optic Back light.

6. ESD Anti-Static Design: using Aluminum Foil, Printing AG or C plasma , ITO Film anti-static











Main Technical Parameters
(1) Electrical Properties
1.Operating voltage:  ≤ 50VDC
2.Working current:  ≤ 100mA
3.Contact resistance:  0.5 ~ 5Ω
4.Insulation resistance:  ≥ 100MΩ (100VDC)
5.Substrate voltage:  2kDVC
6.Spring time:  ≤ 6ms
7.Loop resistance:  30Ω
8.Insulation ink voltage:  100VDC

(2) Mechanical Properties
1. reliability, service life: > 1 million times
2. closed displacement:

0.1 ~ 0.4mm (no touch-type)

0.4 ~ 1.0mm

3. health standard for power:  280g Power
4. silver migration:

In 55 ℃, humidity 90%, 56

hours later, the second-line between the 10MΩ/50VDC

5. silver online no oxidation, no impurities
6.silver width

 ≥ 0.3mm, the smallest interval of

0.3mm, line edges <1 / 3, the

line gap of <1 / 4 width

7.pin spacing standard  2.54mm
8.lead anti-curvature, with d

10mm steel rod line pressure roller

80 constantly.


(3) environmental performance
1. operating temperature:  -40 ℃ ~ +80 ℃
2. storage temperature:  -40 ℃ ~ +85 ℃ temperature of 95% ± 5%
3. atmospheric pressure:  86 ~ 106kDa

(4) print index
1. print size deviation

± 0.15mm, clear code looks

bad ≤ 0.1mm edges

2. chromatic deviation

± 0.11mm/100mm, insulated cover all

 the Silver Line Ink

3. no ink dispersion, writing non-defective
4. chromatic aberration is not more than two
5. may have creases, paint stripping

6. transparent windows transparent clean, uniform color, not a scratch, and impurity



Overlay Material
PET, PC,Metal,Silicone
Artwork Format
CorelDraw, Adobe Illustrator AI, AutoCAD, CDR
Color
Pantone and RALcolor matching system
Button
Embossed/Flat/Metal/Silicone/Rubber
Keys Options
Tactile: metal domes or poly domes
Non-tactile: flat button, printed silver spot on the circuit
Connector Tail
Zero insertion force(ZIF) with 0.5MM ,1.0MM,1.25MM pitch
Female connector with 2.54MM pitch
Circuitry option
Silver printed conductive inks, FPC, PCB
Printing
Screen printing, Semi-Auto matic printing, Automatic Printing
Window
Clear or transparent, translucent, red/black/white/green etc transparent window
Surface
Glossy surface or matte surface
Rear Adhesive
3M467,3M468, 3M9080, 3M9495, 3M7959,3M9471, 3M300VHB, etc...
Certificate
ISO9001、RoHS、CE、SGS
